Product
Product Center
Product List
Emergency lighting centralized power supply (explosion-proof type)

Emergency lighting centralized power supply (explosion-proof type)

Emergency lighting centralized power supply (explosion-proof type)

Explosion proof rating: Ex db eb IIB T6 Gb; Ex db eb IIC T6 Gb； Ex t IIC T80℃ Db● Integrated design of fire safety standards and explosion-proof requirements;  ● The shell is made of aluminum alloy die-casting or steel plate welding surface high-voltage electrostatic spraying, or stainless steel welding formed stainless steel exposed fasteners;  ● Automatic conversion between primary and backup power, capable of manual forced start, providing emergency power for the rear lighting fixtures;  ● Integrated design of centralized power supply and distribution power supply, A centralized power supply safe voltage output, in compliance with new standards;  ● Automatically perform periodic charging and discharging checks on equipment, as well as monthly and yearly checks on operating status, achieving unmanned operation;  ● Equipped with multiple protections such as open circuit, overload, undervoltage, and overcurrent;   ● Equipped with external communication control ports such as CAN, RS485, dry contacts, and mains power detection, it enables remote control of the controller, FAS, and linkage of mains power loss;  ● Chinese LCD display.

Learn more
Medium sized explosion-proof marker light

Medium sized explosion-proof marker light

Medium sized explosion-proof marker light

Explosion proof rating: Ex eb ib mb IIC T6 Gb; Ex tb IIIC T80℃ Db● Non polarized wiring;  ● Handheld encoder encoding;  ● Short circuit independent recoverable protection;  ● Wide voltage power supply;  ● Die cast aluminum high heat dissipation shell;  ● Working voltage (V): DC20V~DC36;● Communication method: R-BUS power supply+communication two bus;  ● Panel material: die cast aluminum+tempered glass (explosion-proof);  ● Rated power (W):<4;  ● Protection level: IP67;  ● Function: Inspection, constant flashing, turn off lights;  ● Application scenarios: pipe gallery, chemical, anti-corrosion, and explosion-proof places.

Learn more
Large explosion-proof marker light

Large explosion-proof marker light

Large explosion-proof marker light

Explosion proof rating: Ex eb ib mb IIC T6 Gb; Ex tb IIIC T80℃ Db● Non polarized wiring;  ● Handheld encoder encoding;  ● Short circuit independent recoverable protection;  ● Wide voltage power supply;  ● Die cast aluminum high heat dissipation shell;  ● Working voltage (V): DC20~DC36;● Communication method: R-BUS power supply+communication two bus;  ● Panel material: die cast aluminum+tempered glass (explosion-proof);● Rated power (W): ＜ 4W;  ● Protection level: IP67;  ● Function: Inspection, constant flashing, turn off lights;  ● Application scenarios: pipe gallery, chemical, anti-corrosion, and explosion-proof places.

Learn more
Explosion proof emergency lighting

Explosion proof emergency lighting

Explosion proof emergency lighting

Explosion proof rating: Ex db IIC T6 Gb/Ex tb IIIC IP67 T80 ℃ Db● Non polarized wiring● Handheld encoder encoding● Short circuit independent recoverable protection● Wide voltage power supply● Die cast aluminum high heat dissipation shell● Power supply mode: centralized power collection and control● Communication method: R-BUS power supply+communication two bus;  ● Shell material: die cast aluminum+tempered glass● Light source: LED● Protection level: IP67● Working voltage (V): DC20~DC36● Function: Inspection, light source monitoring, mandatory emergency response

Learn more
BX series explosion-proof intelligent distribution box (cabinet)

BX series explosion-proof intelligent distribution box (cabinet)

BX series explosion-proof intelligent distribution box (cabinet)

Explosion proof rating: Ex db llB T4/T6 Gb; Ex db IIC T4/T6 Gb； Ex tb lIlC T80℃ Db● The shell is made of aluminum alloy die-casting or steel plate welding, with high-voltage electrostatic spraying on the surface, or stainless steel welding formed, with exposed stainless steel fasteners;  ● This series of products features a flameproof structure;  ● Adopting intelligent lighting modularization, remote operation can be achieved through the Internet of Things;  ● Equipped with high breaking miniature circuit breakers or molded case circuit breakers, which can be opened and closed by operating the handle on the casing cover;  ● Inlet and outlet threads: NPT1/2~NPT4/M20~M115 × 1.5;  ● Steel pipe or cable wiring;  ● Rated voltage (V): 24, 36, 110, 220, 230, 240, 380, 415, 500, 690;  ● Main switch current (A): ≤ 800;  ● Branch current (A): ≤ 500.

Learn more
BXM (D) series explosion-proof lighting (power) distribution box

BXM (D) series explosion-proof lighting (power) distribution box

BXM (D) series explosion-proof lighting (power) distribution box

Explosion proof rating: Ex db eb llB T4/T6 Gb; Ex db eb IIC T4/T6 Gb； Ex tb llIC T80℃ Db● The shell is made of aluminum alloy die-casting or steel plate welding, with high-voltage electrostatic spraying on the surface, or stainless steel welding formed, with exposed stainless steel fasteners;  ● This series of products features a composite structure, with the main chamber adopting an explosion-proof structure and the wiring chamber adopting an increased safety structure;  ● Adopting modular design, various circuits can be freely combined;  ● Equipped with high breaking miniature circuit breakers or molded case circuit breakers, which can be opened and closed by operating the handle on the casing cover;  ● Inlet and outlet threads: G1/2~G4/M20~M115 × 1.5;  ● Steel pipe or cable wiring;  ● Rated voltage (V): 24, 36, 110, 220, 230, 240, 380, 415, 500, 690;  ● Main switch current (A): ≤ 630;  ● Branch current (A): ≤ 500.

Learn more
BXX series explosion-proof maintenance (socket) box

BXX series explosion-proof maintenance (socket) box

BXX series explosion-proof maintenance (socket) box

Explosion proof rating: Ex db eb llB T4/T6 Gb; Ex db eb IIC T4/T6 Gb； Ex tb llIC T95℃ Db● The shell is made of aluminum alloy die-casting or steel plate welding, with high-voltage electrostatic spraying on the surface, or stainless steel welding formed, with exposed stainless steel fasteners;  ● This series of products features a composite structure, with the main chamber adopting an explosion-proof structure and the wiring chamber adopting an increased safety structure;  ● Multiple sockets can be configured;  ● It is equipped with a high breaking circuit breaker, which can be opened and closed by operating the handle on the cover of the shell, and is equipped with a connection display signal light;  ● Inlet and outlet threads: G1/2~G4/M20~M115 × 1.5;  ● Steel pipe or cable wiring;  ● Rated voltage (V): 24, 36, 110, 220, 230, 240, 380, 415, 500, 690;  ● Socket current (A): 16, 32, 63.

Learn more
BLK series explosion-proof circuit breaker

BLK series explosion-proof circuit breaker

BLK series explosion-proof circuit breaker

Explosion proof rating: Ex db eb llB T4/T6 Gb; Ex db eb IIC T4/T6 Gb； Ex tb llIC T80℃ Db● The shell is made of aluminum alloy die-casting or steel plate welding, with high-voltage electrostatic spraying on the surface, or stainless steel welding formed, with exposed stainless steel fasteners;  ● This series of products features a composite structure, with the main chamber adopting an explosion-proof structure and the wiring chamber adopting an increased safety structure;  ● Equipped with high breaking miniature circuit breakers or molded case circuit breakers, which can be opened and closed by operating the handle on the casing cover;  ● Overload and short circuit protection, as well as infrequent switching of electrical devices and lighting circuits under normal circumstances;  ● Distribute electrical energy and protect lines and power equipment from damage caused by overload, short circuit, and other faults, while also serving as infrequent starting and short circuit protection for electric motors;  ● Steel pipe or cable wiring;  ● Rated voltage (V): 24, 36, 110, 220, 230, 240, 380, 415, 500, 690;  ● Rated current (A): ≤ 500.

Learn more
BXK series explosion-proof control box

BXK series explosion-proof control box

BXK series explosion-proof control box

Explosion proof rating: Ex db eb llB T4/T6 Gb; Ex db eb IIC T4/T6 Gb； Ex tb llIC T80℃ Db● The shell is made of aluminum alloy die-casting or steel plate welding, with high-voltage electrostatic spraying on the surface, or stainless steel welding formed, with exposed stainless steel fasteners;  ● It can be equipped with indicator lights, buttons, universal transfer switches, ammeters, voltmeters, etc. Other instruments can be installed according to user requirements;  ● The control switch has a compact structure, high reliability, small size, strong switching ability, long service life, and multiple functions for users to choose from;  ● Rated voltage (V): AC 460, 380, 220, 110, 36/DC 220, 110, 36, 24● Rated current (A): ≤ 200.

Learn more
